Lifting vacuum dry mill
Lifting vacuum dry mill
Meet GMP requirement
The machine is mainly used in the pharmaceutical industry to pelet the granules after granulation,and miling into uniform granules according to the process requirements. It is aiso widely used in such industries as medicine,chemical industry,food,etc
Detailed introduction
Work principle
During operation,the materials are sucked into the buffer tank through the vacuum feeder.The granules flow from the buffer tank to the cavity of the granulator,and the granules in the cavity are subjected to impact,extrusion,shearing,and then discharged through the screen hole,and flow through the discharge port of the guide tube to the hopper.In the closed premise to complete the material transfer,the whole process.
Features
1.The machine height of lifting or falling.Meet clients'requirements.
2.The whole process in a closed state to complete,to avoid dust flying,no pollution.
3.Meet GMP requirements.
Technical parameter
| Item Model | ZLZ-100 | ZLZ-200 | ZLZ-300 | ZLZ-500 | ZLZ-700 | |
| Lifting motor power（kw） | 1.5 | 2.2 | 2.2 | 3 | 3 | |
| Mill motor power（kw） | 1.1 | 3 | 3 | 3 | 4 | |
| Screen specification（mm） | d0.6-3 | d0.6-3 | d0.6-3 | d0.6-3 | d0.6-3 | |
| Production capacity（kg/h） | 100 | 450 | 450 | 450 | 700 | |
Outline dimensions | H | Designed according to process requirements | ||||
| H1 | ||||||
| L | ||||||
